The AS/CAM3 is suitable to be connected to a maximum of three milling machines. It is equipped with a new generation of universal motors, with a total power of 3000 W single phase 230V, and an electronic microprocessor control that increases o decreases the power to the motors depending on requirements .
The motors do not require replacement of the carbon brushes, and they have an average life of approximately 2500 hours.
The unit has a main sack filter, with a surface area of 7300 cm² and a secondary cartridge filter of 3650 cm² for each motor.
The two filters together comply with grade “H” of filtration under the EN-60335-2-69 standard.
The air is discharged by mean of a 7.5 cm pipe direct to atmosphere, reducing air temperature and recycling of untreated dust. Suction activation can be manual, or on request, automatic using a interface designed for any milling machine.
The unit is equipped with a sensor that check the status of the filters and in case of filters full, activates a red warning light and switches off the motors activating stand by status.
· Air discharge on the right or left.
· Box for suction distribution on the right or left.
· Noise: 70 dBa.
· Dimensions: 78,5x43x71H cm.
